Electrical
Rated Current 4A (each feed)
Rated Voltage
60VDC
Mechanical
- Female Contact Phosphor bronze, gold plated
- Contact Carrier PA66 (30% Glass Filled), Black
- Contact Polarisation Standard M12 -“A”- polarisation
- Mating Thread M12
- Screw Cap Brass, nickel plated
- O-Ring Seal Rubber, black
- Housing PVC, black/orange
- Cable Jacket Material 0.8mm Nom. PVC, orange
- Cable Outer Diameter 6.7mm ±0.254mm
- Cable Length 3M
- Wire Length 100mm (7mm stripped)
- Wire Jacket PVC
- Wires 18 AWG (stripped and tinned)
- Drain 18 AWG (34 strand tinned copper)
- Shield Al-mylar
- Weight 290g
