Spesifikasjon
| Input Frequency |
1575.42MHz±1.023MHz |
| Polarization |
R. H. C. P. (Right Hand Circular Polarization) |
| Antenna Gain |
>= 2.0dBi (at 90° elev. angle) |
| >= -4.0dBi (at 10° elev. angle) |
| Output Impedance |
50 Ω |
| Pre. Amp Gain |
27.5±5.5dB |
| Pre. Amp Noise Figure |
<= 1.6dB |
| VSWR |
<= 2.0 |
| Supply Voltage |
4 to 5.5VDC |
| Current Consumption |
<= 25mA |
| Operating Temperature |
-25°C to +70°C |
| Storage Temperature |
-35°C to +75°C |
| Operating Relative Humidity |
<= 95% Relative Humidity |
| Weight |
120g |
| Connector Type |
TNC-J |
| Cable lenght |
10m |
Kan erstatte GPA-C01 og motsatt
